6AG1688-3AF37-2AX0 KP8 Operator Panel Keypad Plastic Case
| Brand | SIEMENS |
|---|---|
| Model | 6AG1688-3AF37-2AX0 |
| Warranty | 6 Months |
| Product Line | KP8 Series |
| Supply | Plastic Enclosure Terminal Keypad |
| FOB port | Guangzhou, Shenzhen, Hongkong |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, Credit Card |
| Download | |
| Update Time | 2026-01-30 20:27:39 |
Shipping
Free Shipping
Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.
6AG1688-3AF37-2AX0 Siemens HMI KP8 membrane keypad HMI Case Power Connector Main Board Mounting Clips Repair Replacement
The 6AG1688-3AF37-2AX0 Membrane Switch Keypad HMI device shows you operating states of a plant. You can actively control a running production process based on this information.
The 6AG1688-3AF37-2AX0 Keypad Membrane Switches HMI device is designed for mounting in control panels, and replaces keys and LEDs that are individually mounted. The 6AG1688-3AF37-2AX0 HMI device is connected via PROFINET to a SIMATIC controller.
The 6AG1688-3AF37-2AX0 Membrane Keypad Overlay HMI device is parameterized for immediate use. In comparison to conventional wiring, substantially less time is needed for commissioning and the device provides increased security against failure during runtime.
The KP8 and the KP8F are intended for installation in the following extension units:
● Extension Unit 15", Order number 6AV7674-0KG00-0AA0
● Extension Unit 19" left, order number 6AV7674-0KH00-0AA0
● Extension Unit 19" right, order number 6AV7674-0KJ00-0AA0
Kernfix supply 6AG1688-3AF37-2AX0 Siemens KP8 membrane switch, Power Connector, Main Board, Mounting Clips and Plastic Shell with 6 months warranty and support Urgent Worldwide Shipping.
Specifications:
| Part Number: | 6AG1688-3AF37-2AX0 |
| Product Type: | KP8 |
| Membrane keyboard: | Yes |
| Product Line: | Siemens KP8 series |
| Warranty: | 6 mouths Warranty |
| Function Keys: | 8 |
| Rated value (DC): | 24 V |
| Short-stroke Keys: | 8 |
| Mounting Position: | vertical |
| Mounting Type: | Mounting clip |
Related BB Teach Pendant Part No. :
| 6AG1688-3AF37-2AX0 | Description | Inventory status |
| 6AG1688-3AF37-2AX0 | Siemens KP8 Series Membrane Keypad Overlay | Available Now |
| 6AG1688-3AY36-2AX0 | SIMATIC HMI KP8 Membrane Keyboard Repair | In Stock |
| 6AG1688-3XY38-2AX0 | Siemens KP8 Series Membrane Keypad Switch Repair | In Stock |
| 6AV3688-3AF37-0AX0 | SIMATIC HMI KP8 HMI Keypad Membrane Switch Replacement | In Stock |
| 6AV3688-3AY36-0AX0 | SIMATIC HMI KP8 Membrane Switch Keypad Replacement | Available Now |
| 6AV3688-3XY38-3AX0 | SIMATIC HMI KP8 Membrane Keyboard Keypad Repair | In Stock |
6AG1688-3AF37-2AX0 KP8 Operator Panel Keypad Plastic Case PDF Download:
FAQ:
Question: 6AG1688-3AF37-2AX0 Mounting position
Answer: Select one of the approved mounting positions for your HMI device. The following figure shows the front and side view of the permitted mounting positions using the KP8(F) as an example; it applies to the KP32F in the same way.
Question: What is the 6AG1688-3AF37-2AX0 Siemens KP8 series HMI parts price?
Answer: Submit a fast quote, send Kernfix an email for best price.
Question: How to install SIMATIC KP8 6AG1688-3AF37-2AX0 Labeling keys?
Answer: The following figure shows the KP8F as an example.
