Advantech TPC-315-R833B TPC-315-R853B TPC-315-R873B Overlay Film Touch Repair

Order each part separately is available

Installation Proccess

With easy installation of HMI Advantech Control Panel TPC-315 Series TPC-315-R833B TPC-315-R853B TPC-315-R873B Touch Screen Monitor Front Overlay, a person can complete panel mount process by himself, just follow following steps:
Step 1: Release the 2 screws in the top of TPC and the snap hook will arise.
Step 2: And then release the 2 screws in the bottom of TPC.
Step 3: Set TPC cross the cut-out hole and push it into the wall, the snap hook will hold the machine on the wall.
Step 4: Panel-mount installation of Advantech HMI TPC-315-R833B TPC-315-R853B TPC-315-R873B Protective Film Touch Digitizer Glass complete

Note

While using easy installation, the suggested mounting panel thickness for Advantech screen TPC-315-R833B TPC-315-R853B TPC-315-R873B Touch Screen Glass Front Overlay is less than 2 mm (0.079"). When without easy installation, the suggested mounting panel thickness is less than 6 mm (0.236").

Easy Installation

The Advantech touch screen TPC-315-R833B TPC-315-R853B TPC-315-R873B Protective Film HMI Panel Screen specifications include a light transmission rate of 288%, providing vibrant display quality. With a resolution of 4096 x 4096 dots, it offers sharp and detailed imagery. It utilizes a projected capacitive technology, ensuring accurate touch response and enhanced usability.
