B&R 5MP050.0653-04 Touch Panel Membrane Keypad
| Brand | B&R |
|---|---|
| Model | B&R Mobile Panel 50 5MP050.0653-04 |
| Warranty | 1 Year VICPAS Warranty |
| Shipping | DHL/FedEx/UPS/TNT/EMS/Aramex /DPEX |
| Terms of Payment | Western Union, T/T, PayPal, T/T ,Credit Card, Western Union |
| Download | |
| Update Time | 2026-01-30 23:47:06 |
Shipping
Free Shipping
Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.
B&R Mobile Panel 50 5MP050.0653-04 Touch Screen Glass Membrane Keypad Repair
Order each part separately is available
Control and display panel
• Membrane keys with mechanical pressure point
• 4 (on MP40) or 7 (on MP50) LED status indicators
• Buzzer
An MP100/200 can be connected to the system in place of an MP40/50. The attachment cables feature the same circular connectors allowing for simple exchange by removing and inserting. When connecting an MP40/50, the differences between the devices must be taken into consideration.
5MP050.0653-04 Electronics
• CPU Intel PXA270/416 MHz
• Memory expansion:
° SDRAM: 256 MB
° FLASH: 128 MB
Specifications:
| Part Number: | 5MP050.0653-04 |
| Product Line: | Mobile Panel 50 |
| Screen diagonal: | 6.5 in |
| Warranty: | 365 Days Warranty |
| Input Power: | 24 VDC |
| Display Type: | TFT color |
| Mounting position: | Vertical |
| Input Type: | Keypad |
| Serial interface Type: | RS232 |
| Storage: | -20 to 70°C |
Related BB Teach Pendant Part No. :
| B&R Mobile Panel 50 5MP050.0653-04 | Description | Inventory status |
| 5MP050.0653-01 | B&R Mobile Panel 50 Touch Screen Panel Glass Operator Keyboard | In Stock |
| 5MP050.0653-02 | Mobile Panel 50 Touch Panel Glass Keyboard Membrane Replacement | Available Now |
| 5MP050.0653-03 | B&R Mobile Panel 50 Touch Screen Panel Switch Membrane Repair | In Stock |
| 5MP050.0653-04 | B and R Mobile Panel 50 Touch Digitizer Membrane Switch Replacement | Available Now |
| 5MP050.0653-K01 | Mobile Panel 50 HMI Touch Screen Organizer Switch Membrane | Available Now |
| 5MP050.0653-K03 | Mobile Panel 50 Touch Panel Membrane Switch Keypad Repair | In Stock |
| 5MP050.0653-K04 | Mobile Panel 50 HMI Touch Screen Monitor Keypad Membrane | Available Now |
| 5MP050.0653-K05 REV.E0 | Mobile Panel 50 HMI Touch Glass Membrane Keypad Overlay | In Stock |
B&R 5MP050.0653-04 Touch Panel Membrane Keypad PDF Download:
FAQ:
Question: What is Image Persistence of 5MP050.0653-04?
Answer: Image persistence refers to the "burning in" of a static image on a display after being displayed for a long time. It does not only occur with static images, however. Image persistence is also referred to in the technical literature as screen burn-in, image retention, memory effect, memory sticking or ghost image. There are 2 different types: • Area type: This type can be seen in a dark gray image. The effect disappears if the display is switched off for a long time. • Line type: This can result in permanent damage.
Question: How can 5MP050.0653-04 image persistence be reduced?
Answer: • Switch continuously between static and dynamic images.• Prevent excessive differences in brightness between foreground and background elements.• Use colors with similar brightness.• Use complementary colors for subsequent images.• Use screensavers.
Common misspellings:
MP050.0653-04
5MP50.0653-04
5MP050.6053-04
5MPO50.0653-04
5MP050.00653-04
