Beijer E1000 Operator Panel E1061 603221128 Touch Screen
| Brand | BEIJER |
|---|---|
| Model | Mitsubishi Beijer E1061 |
| Warranty | 365 Days |
| Product Line | E1000 Operator Panel |
| Supply | Beijer E1061 Touch Screen and Overlay |
| FOB port | Guangzhou, Shenzhen, Hongkong |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, Credit Card |
| Download | |
| Update Time | 2026-01-31 00:41:04 |
Shipping
Free Shipping
Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.
E1061 603221128 Beijer E1000 Series Touchscreen Repair Replacement
Beijer E1061 603221128 320 x 240 pixels HMI Repair kit
320 x 240 pixels
TFT display
5.7" TFT-LCD screen
Project storage 12 MB
Operating temperature 0 to +50 °C
Ethernet and serial
Touch display
The E1000 operator panel is developed to satisfy the demands ofhuman-machine communication. Built-in functions such as displaying and controllingtext, dynamic indication, time channels, alarm and recipe handling are included.The operator panel work, for the most part, in an object-oriented way, making it easyto understand and use. The configuration operation of the panel is made in a personalcomputer, using the configuration tool E-Designer. The project is then transferredand stored in the operator panel.
Kernfix supply Beijer Exter E1061 Touch Panel with 365 days warranty and support Urgent Worldwide Shipping.
Specifications:
| Brand: | Beijer |
| Numerical keypad: | YES |
| Input fuse: | Internal DC fuse |
| Warranty: | 365 Days Warranty |
| Product Line: | Beijer E1061 |
| Size diagonal: | 320 x 240 pixels |
| Part Number: | 603221128 |
| Housing material: | Powder-coated aluminium, grey |
| Input voltage: | 20 - 30 V DC |
| Display type: | TFT CCFL |
Beijer E1000 Operator Panel E1061 603221128 Touch Screen PDF Download:
FAQ:
Question: How to install the Beijer E1061 Operator Panel?
Answer: 1. Unpack and check the delivery. If damage is found, notify the supplier. 2.Place the panel cut out where the operator panel is to be situated, draw along theouter sides of the holes and cut according to the markings.3.Secure the operator panel in position, using all the fastening holes and theprovided brackets and screws:4.Connect the cables in the specified order.5.Carefully remove the laminated film over the operator panel display, to avoidstatic electricity that could damage the panel.
Question: Why is the general information about Beijer E1061 Software?
Answer: The software required to run and maintain the operator panels is found on the softwareCD. It is also available through your local distributor.The software is tested by the manufacturer’s own testing department before marketintroduction is approved. The test procedure is closely integrated with the developmentprocess. The test group works in close concert with the developers and is ISEBCertified for Software Testing
Question: What is E1061 603221128 Beijer E1000 Series Operator Panel Touchscreen and Overlay HMI parts price?
Answer: Submit a fast quote, send Kernfix an email for best price.
