Membrane keyboard forEXTER K30 membrane keypad switch

Product Description:

Material	Polyester or Polycarbonate
Artwork Format	CorelDraw, Adobe Illustrator AI or EPS, AutoCAD Dwg or DXF
Tactile Feel	Is determined by the thickness of the overlayer. Normally between 0.06” -0.08".
Conductive Trace	Silver or Copper
Dome	Stainless Steel or Mylar
Actuation Force	Depend on customer's requirement. Normally between 30-600 grams.
Travel	Depend on customer's requirement. Normally between 0.010" - 0.020".
Life Cycle	5 Million Cycles(up to)

Operating voltage: 35V DC
Operating current: 100mA 1W
Contact resistance:
Open circuit resistance: ≥ 10MΩ at 100V

Operating temperature: Flat/Metal dome:-20°c to +80°c

Storage temperature: Flat/Metal dome:-40°cto +80°c

Life expectancy Flat type≥5,000,000 times Tactile type≥1,000,000 times

Switch stroke: 0.1 to 0.6mm
Contact bounce: 5 to 30ms
Actuation force tolerance: +/- 20 to 45g
Tactile ratio: FC > 40%
Operating humidity: up to 95% RH
Female, male connector, solder pins and heat seal connectors are available

Advantageous features of Membrane keypad :
1.Ability to integrate graphics including logos
2.Inherent moisture resistance,durability ,HeatSeal Reliability
3.Lower cost
4.Ease of cleaning & sanitizing, good sealed performance so that Provide Harsh & Rugged Environmental solutions

5.Ease of customizing,Reduced space&weight, stable structure

LED, metal domes, connector and circuit, all these can be designed and made according to customer requirements . all custom are available

More details:

Specifications:

Membrane keyboard for EXTER K30 membrane keypad switch PDF Download:
