IDEC HG1F-SB22YF-B Overlay Film Touch Monitor Repair

Order each part separately is available

Maintenance and Inspection of HG1F-SB22YF-B Front Overlay Touch Screen Display

Maintain and inspect the IDEC HG1F-SB22YF-B Touch Digitizer Glass Overlay Film periodically to ensure the best performance. Do not disassemble, repair, or modify the HG1F-SB22YF-B MMI Touch Glass Protective Film during inspection. Wipe any stain off the display using a soft cloth slightly dampened with neutral detergent or alcoholic solvent. Do not use solvents such as thinner, ammonia, strong acid, and strong alkaline. Check the terminals and connectors to make sure of no loose screws, incomplete insertion or disconnected lines. Make sure that all mounting clips and screws are tightened sufficiently.If the mounting clips are loose, tighten the screw to the recommended tightening torque.

Adjusting the HG1F-SB22YF-B Touch Panel Front Overlay

A gap may be caused in the operation accuracy of the touch panel by the secular distortion, etc. Readjust the touch panel when there is a gap in the operation of the touch panel.

Panel Cut-out Dimensions of HG1F-SB22YF-B Protective Film Touchscreen

Place the IDEC HG1F in a panel cut-out and fasten with the attached mounting clips. Do not tighten excessively, otherwise the HG1F-SB22YF-B Touch Membrane Overlay Film may warp and cause wrinkle on the display, or impair the waterproof characteristics.

Note for operation

The screen becomes blank when the backlight is burnt out; however, the HG1F-SB22YF-B Front Overlay Touch Digitizer Glass remains enabled. Incorrect touch panel operation will occur when operating the touch panel when the backlight appears to be turned off but is actually burnt out. Note that this erroneous operation may result in damage.
