Home / All / for Siemens / Simatic KTP400~KTP1200 Series / 6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen

6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen

6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen
6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen
BrandSIEMENS
Model6AV2 125-2JB03-0AX0
Warranty365 Days
Product LineKTP900 Basic
SupplySiemens KTP900 HMI Touch Panel LCD Display
PartsEnable Switch
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download
Update Time2026-02-03 20:50:40
Leading Time{{selectedConditionObj.leading}}
{{item.value}}
{{nameObj.name}}{{nameObj.selectedValue}}
{{valueObj.name}}

Shipping

Free Shipping

Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.

Detail Information

6AV2125-2JB03-0AX0 Simatic HMI KTP900 mobile 6AV2 125-2JB03-0AX0 Touchscreen Panel Glass, Overlay, Enabling Controller Switch and LCD Display Repair Replacement

Order each part separately is available

6AV2125-2JB03-0AX0 Simens Simatic HMI KTP900 Basic Touchscreen Panel Glass, Overlay, Enable Switch and LCD Display Repair Replacement

6AV2 125-2JB03-0AX0 SIMATIC HMI KTP900 MOBILE, 9.0'' TFT DISPLAY, 800 X 480PIXELS,16M COLOR, KEY AND TOUCH OPERATION, 10FUNCTION KEYS, 1 X PROFINET/INDUSTRIAL ETHERNET INTERFACE; 1 X MULTIMEDIA CARD, 1 X USB, CONFIGURABLE FROM WINCC COMFORT V13 SP1


The visualization of Siemens KTP900 Basic allows for considerably increased process quality with compact plants or smaller applications. Featuring all important HMI basic functions, SIMATICHMI Basic Panels Generation thus open up completely new possibilities in terms of operation and monitoring also in the field of mechanical engineering at a particularly attractive price.Besides, These also support vertical configuration. Their high resolution and color depth of 64,000 colors facilitate improved process visualization. The displays brightness is dimmable up to 100 %, offering optimum flexibility.


Kernfix supply 6AV2125-2JB03-0AX0 Siemens KTP900 Basic touch panel, Overlay, Enabling Controller Switch and LCD display. All of them with Kernfix 365 days warranty and support Urgent Worldwide Shipping.






  Contact Best Price

Specifications:

Part Number:6AV2125-2JB03-0AX0
Touchscreen:colour LCD display
Design of display:TFT widescreen display
Warranty:365 days Warranty
Product Line:Siemens KTP900 Basic
Power consumption, typ.:11 W
Mounting position:vertical
Key Features:Touch screen support
Language:Worldwide
Processor type:ARM


Related BB Teach Pendant Part No. :

6AV2 125-2JB03-0AX0Description Inventory status
6AV2125-2JB03-0AX0SIMATIC HMI KTP900 MOBILEIn Stock
6AG1123-2JB03-2AX0SIPLUS HMI KTP900 BASICIn Stock
6AV2123-2JB03-0AX0SIMATIC HMI KTP900 BASICAvailable Now
6AV2125-2JB23-0AX0SIMATIC HMI KTP900F MOBILEIn Stock

6AV2125-2JB03-0AX0 Simatic HMI KTP900 Mobile Touchscreen PDF Download:

  • SIMATIC KTP Basic
  • 6AV2125-2JB03-0AX0 SIMATIC HMI KTP900 Mobile datasheet pdf
  • Siemens Simatic KTP900 Basic HMI touchpanel manual

    • FAQ:

    Question: What is the size of 6AV2125-2JB03-0AX0 Siemens KTP900 touch panel??

    Answer: The Siemens KTP900 Basic TouchScreen is 9-inch.It is 215.5 millimeter long and 129.3 millimeters wide.

    Question: How to reset Siemens Simatic KTP900 to factory state?

    Answer: To restore the factory settings on the HMI device, follow these steps:1. Set the HMI device to "bootstrapping" mode.– Open the "OP Properties" dialog on the HMI device in the Control Panel.– Switch to the "Device" tab and select "Reboot".The "Attention" dialog box opens.– Select "Prepare for Reset".The HMI device restarts and switches to "bootstrapping" mode. If you do not reset the HMI device to the factory settings, the HMI device restarts after 10 minutes.2. Select the "Update operating system" command in the "Online > HMI device maintenance" menu on the configuration PC in WinCC.The "SIMATIC ProSave [OS-Update]" dialog box opens. The path to the image of the operating system is already set.3. If needed, select another path for the operating system image that you wish to transfer to the HMI device.4. Enable "Reset to factory settings".5. Enter the MAC address of the HMI device.6. Click "Update OS".The operation can take some time.

    Question: What is the 6AV2125-2JB03-0AX0 Siemens KTP900 Basic HMI parts price?

    Answer: Submit a fast quote, send Kernfix an email for best price.


    Common misspellings:

    6A2125-2JB03-0AX0

    6AV125-2JB03-0AX0

    6AV225-2JB03-0AX0

    6AV215-2JB03-0AX0

    6AV212-2JB03-0AX0
