B&R PP500 5PP520.1043-B50 Touch Screen Organizer

B&R PP500 5PP520.1043-B50 Touch Screen Organizer
B&R PP500 5PP520.1043-B50 Touch Screen OrganizerB&R PP500 5PP520.1043-B50 Touch Screen OrganizerB&R PP500 5PP520.1043-B50 Touch Screen OrganizerB&R PP500 5PP520.1043-B50 Touch Screen OrganizerB&R PP500 5PP520.1043-B50 Touch Screen Organizer
BrandB&R
ModelB&R Power Panel 500 5PP520.1043-B50
Warranty1 Year VICPAS Warranty
Touch Screen Panel TypeResistance touch screen
ShippingDHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Download
Update Time2026-02-03 23:31:06
Leading Time{{selectedConditionObj.leading}}
{{item.value}}
{{nameObj.name}}{{nameObj.selectedValue}}
{{valueObj.name}}

Shipping

Free Shipping

Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.

Detail Information

B&R Power Panel 500 5PP520.1043-B50 Touch Screen Glass Repair Replacement

Order each part separately is available

Power Panel 500 5PP520.1043-B50 Touch Screen Panel

The PP500 5PP520.1043-B50 system can be assembled to meet individual requirements and operating conditions.
The following components are absolutely essential for operation:
System unit
CPU board
Main memory
Drive (mass storage device such as CompactFlash card) for the operating system
Power connector (terminal block)


B&R touch screen devices are equipped with a touch controller that supports hardware calibration. This means that the devices are pre-calibrated from stock. This feature proves advantageous in the case of a replacement part because a new calibration is no longer required when exchanging devices (identical model / type). Nevertheless, we recommend calibrating the device in order to achieve the best results and to better readjust the touch screen to the user's preferences. Windows CE starts the touch screen calibration sequence during its first boot in the default configuration / delivered state. After first starting Windows XP embedded (First Boot Agent), the touch screen driver must be installed in the device in order to operate the touch screen. The corresponding drivers can be downloaded from the download area on the B&R homepage (www.br-automation.com). The touch screen should be calibrated during driver installation. The first time the touch screen is used, it must be calibrated once in the customer application for the existing device and project.


The PP500 features a USB 2.0 (Universal Serial Bus) host controller with multiple USB interfaces, 2 of which are accessible externally for the user. PP500 devices with a display size of 10.4", 12.1" or 15" are also equipped with a USB interface on the front of the device.



  Contact Best Price

Specifications:

Part Number:5PP520.1043-B50
Product Line:Power Panel 500
Screen diagonal:10.4 in
Warranty:365 Days Warranty
Input Power:24 VDC
Display Type:TFT color
Mounting position:Vertical
Input Type:Touchscreen
Serial interface Type:RS232
Storage:-20 to 70°C


Related BB Teach Pendant Part No. :

B&R Power Panel 500 5PP520.1043-B50Description Inventory status
5PP520.0702-K06B&R Power Panel 500 Touch Screen Panel Glass Protective FilmIn Stock
5PP520.0702-K08Power Panel 500 B and R Touch Panel Glass ReplacementAvailable Now
5PP520.0702-B10B&R Power Panel 500 Touch Screen Panel RepairIn Stock
5PP580.0844-K01B and R Power Panel 500 Touch Digitizer ReplacementIn Stock
5PP520.1043-00Power Panel 500 B&R HMI Touch Screen OrganizerIn Stock
5PP520.1043-K23B and R Power Panel 500 Protective Film Touch Panel GlassIn Stock
5PP520.1043-K065PP520.1043-K06 Rev. D0 HMI Touch Screen Organizer LCD DisplayAvailable Now
5PP520.1043-B00Power Panel 500 B&R Touch Screen Monitor ReplacementIn Stock
5PP520.1043-B10B and R Power Panel 500 Touch Screen Hmi MonitorAvailable Now
5PP520.1043-B50B&R Power Panel 500 Touch Panel Glass Organizer ReplacemnetIn Stock
5PP520.1043-K12B&R Power Panel 500 HMI Touch Screen Panel Glass Front OverlayIn Stock

B&R PP500 5PP520.1043-B50 Touch Screen Organizer PDF Download:

  • Power Panel 500
  • B&R Power Panel 500 User's Manual

    • FAQ:

    Question: How to replacing a Power Panel 500 B&R 5PP520.1043-B50 CompactFlash card?

    Answer: The CompactFlash card can be replaced quickly and easily by pressing the ejector (see image) with a pointed object such as a pen.

    Question: How can B&R automation power panel 500 5PP520.1043-B50 screen burn-in be avoided?

    Answer: • By constantly changing between static and dynamic images • By avoiding excessive brightness differences between foreground and background elements • By using colors with similar brightness • By using complementary colors in follow-up images • By using a screensaver


    Common misspellings:

    5PP520.143-B50

    5PP520.1043-850

    5PP520.1o43-B50

    5PP520.1043-B5O

    5PP5200.1043-B50
