Kawasaki 50817-0009 Teach Pendant Parts for Replacement

Order each part separately is available

Safety Precautions

To safeguard the user, parts for Kawasaki 50817-0009 Screws, E-Stop Button Label, Housing, LCD Display Panel, Membrane Switch, Hanger, Key Board, Main Board, Hand Strap, Teach Lock Switch, E-Stop Switch, Lone Line Enable Switch, Short Line Enable Switch, PET Screen Protector, Enable Switch Covers, Cable and Touch Digitizer are equipped with many safety features, including the following
1. All emergency stops are hard-wired.
2. Kawasaki parts 50817-0009 Touch Screen, LCD Panel, E-Stop Button Label, HMI Case, Membrane Keyboard, Screws, Main Board, Hand Strap, Teach Lock Switch, E-Stop Switch, Lone Line Enable Switch, Short Line Enable Switch, PET Screen Protector, Enable Switch Covers, Key Board, Cable and Hanger Teach pendant is equipped with three-position, enabling devices. Enabling devices must be pressed to enable motor power in teach and check modes.
3. Safety circuits of the controllers satisfy requirements of PLe in category 4 defined by ISO 13849-1:2015. Category and Performance level (PL) of Kawasaki parts are determined by the whole system and conditions.
4. (For the robot arms with servo lamp) When the servo ON lamp (located on the mechanical unit) is illuminated, servo motor power is available to the robot and motion is possible.
5. Kawasaki 50817-0009 Hanger, Plastic Shell, Membrane Keypad, Screws, LCD Display, E-Stop Button Label, Hand Strap, Teach Lock Switch, E-Stop Switch, Lone Line Enable Switch, Short Line Enable Switch, PET Screen Protector, Enable Switch Covers, Key Board, Main Board, Cable and Touch Panel Teach pendant are equipped with red mushroom-type E-stop switches. And all robot controllers have external E-stop inputs.
6. All robot controllers are equipped with a redundant dual channel safety circuit. Both channels of the safety circuit must be closed to allow for robot operation in teach and repeat modes.
7. Teach and check mode velocities are limited to a maximum of 250 mm/s (10.0 in/s).
8. Velocities are not limited to 250 mm/s (10.0 in/s) in the Fast Check Mode that satisfy requirements for ISO 10218-1:2011.
9. Optional over travel limit switches are available on JT1, JT2 and JT3 of the arm.
10. Mechanical units have over travel mechanical stop person the JT1, JT2 and JT3 (optional for JT2 and JT3) axes. Mechanical stoppers are capable of stopping the robot at full speed and with maximum payload. See the specifications of the product for details of the mechanical stoppers.
11. All robot axes of parts for Kawasaki 50817-0009 Terminal Keypad, Screws, Touch Screen Glass, Hanger, LCD Screen, Front Case, Back Cover, Cable and E-Stop Button Lable are equipped with 24 VDC electromechanical brakes that engage when power is removed. If the robot loses power unexpectedly, the mechanical unit arm is held in position by the brakes.
