5PC725.1505-K05 Touch Screen 5PC725.1505-K05 Membrane Keypad repair

5PC725.1505-K05 touchscreen size: 15 inch, other custom size is 3.0'' to 24'' . 5PC725.1505-K05 touch membrane adopt to panel display device. 5PC725.1505-K05 touch screen display light transmission: 80%(Meet ASTM D1003). 5PC725.1505-K05 touchscreen temperatureoperating range: -10C ~ 60C. 5PC725.1505-K05 touch panel temperature storage range: -20C ~ 70C. 5PC725.1505-K05 touch screen tablet resistance:300

ProductDescription:

* Size 15 inch;
General Size 3.0'' to 22''
Custom Size 1.0''to 22''
Fit in with Panel display device
* Performance
Resolution(Interpolation) 4096*4096
Linearity Error Response Speed * Mechanical
Input Method Finger or gloved hand (rubber, cloth or leather)
Touch Times More than 1 million touches
Touch Activation Force 20~80g
Surface Durability Meets pencil hardness 3H (per ASTM D3363)
* Optical
Light Transmission 80%(Meet ASTM D1003)
* Environmental
Temperature Operating Range: -10 C ~ 60 C
Storage Range: -20 C ~ 70 C
Relative Humidity Operating Range: 0%~90% RH (no dew falls)
Storage Range: 0% to 95% RH (no dew falls)
Altitude Up to 3, 000m
* Electrical
Operation Voltage Typical +DC 5V
Power Supply USB or RS232
Interface Full Duplex USB 2.0 (Full Speed) Plug and play compatible
Serial RS-232.
Current 5mA~25mA
Electrostatic Endurance No abnormal appearance after 10kv, 100 , 250PF electrostatic used
Isolation Resistance >20M @ DC 25V
Resistance 300 Agency Approvals CE, FCC, RoHS
Operation System Linux/ DOS / Windows ME/95/98 / NT4.0/XP/2000/Mac OS

LED, metal domes, connector and circuit, all these can be designed and made according to customer requirements . all custom are available

To get more Product Feature

Product Display:
