Membrane keyboard for 362740-9121 TF068 membrane keypad switch

ProductDescription:

Material	PolyesterorPolycarbonate
ArtworkFormat	CorelDraw,AdobeIllustratorAIorEPS,AutoCADDwgorDXF
TactileFeel	Isdeterminedbythethicknessoftheoverlayer.Normallybetween0.06-0.08".
ConductiveTrace	SilverorCopper
Dome	StainlessSteelorMylar
ActuationForce	Dependoncustomer'srequirement.Normallybetween30-600grams.
Travel	Dependoncustomer'srequirement.Normallybetween0.010"-0.020".
LifeCycle	5MillionCycles(upto)

Operatingvoltage:35VDC
Operatingcurrent:100mA1W
Contactresistance:
Opencircuitresistance:10Mat100V

Operatingtemperature:Flat/Metaldome:-20cto+80c

Storagetemperature:Flat/Metaldome:-40cto+80c

LifeexpectancyFlattype5,000,000timesTactiletype1,000,000times

Switchstroke:0.1to0.6mm
Contactbounce:5to30ms
Actuationforcetolerance:+/-20to45g
Tactileratio:FC>40%
Operatinghumidity:upto95%RH
Female,maleconnector,solderpinsandheatsealconnectorsareavailable

Advantageous features of Membrane keypad :
1.Ability to integrate graphics including logos
2.Inherent moisture resistance,durability ,HeatSeal Reliability
3.Lower cost
4.Ease of cleaning & sanitizing, good sealed performance so that Provide Harsh & Rugged Environmental solutions

5.Ease of customizing,Reduced space&weight, stable structure

LED, metal domes, connector and circuit, all these can be designed and made according to customer requirements .all custom are available

Moredetails:

Specifications:

Touch screen for 362740-9121 TF068 touch panel membrane touch sensor glass replacement repair PDF Download:
