2711-B5A16L1 Touch Screen Panel Keyboard Keypad Switch

Although it is obsolete, the Allen-Bradley 2711-B5A16L1 operator terminal is still serviceable and still available from DO Supply. The 2711-B5A16L1 is part of Allen-Bradley’s obsolete PanelView 550 series of operator terminals. It is an HMI or a Human-Machine Interface that allows users and programmers to interact with other machines digitally through the PanelBuilder 32 software and physically through one or more Allen-Bradley 2711-NC13 cables and the 2711-B5A16L1’s RS-232 Printer and Download Port and its RS-232 (DF1) Communication Port.

Users and programmers can use the 2711-B5A16L1 HMI operator terminal to control the machine it is interfacing with by entering data and commands through its touchscreen or through its keypad. Users can also monitor the machine’s applications through the 2711-B5A16L1 terminal’s LCD screen. This LCD measures 5.5 inches and its pixel graphics are monochrome blue mode. The 2711-B5A16L1 is a DC-powered terminal that runs on 24V DC. It can store up to 170 KB of data in its application runtime memory.

Kernfix supply 2711-B5A16L1 HMI parts, touchscreen glass, membrane keyboard switch, Memory Card Retainer Base, LCD Display Screen, Plastic Cover, Gasket, Sticker, Gasket, Screws, Case Accessories. All of them with Kernfix 365-day warranty and support Urgent Worldwide Shipping.

The 2711-B5A16L1 terminal supports floating point files, a real-time clock, universal language, and ASCII input and displays, and it is capable of remote downloading with a network or a gateway connection. The 2711-B5A16L1 HMI terminal is rated for indoor use only and it can be protected inside a NEMA Type 12, 13, or 4X indoor-rated enclosure. This terminal is certified by the C-tick, CE, Class I Division 2, Class I Zone 2, Class II Division 2, Class III Division 1, CUL, and UL specifications for safe operation in a variety of industrial environments in several countries.
