ESA Text HMI VT130W VT130W00000 Membrane Keyboard Replacement
| Brand | ESA |
|---|---|
| Model | VT130W00000 |
| Warranty | 180 Days |
| Product Line | VT Text |
| Supply | VT130W Membrane Keypad |
| Terms of Payment | Western Union, T/T, PayPal, T/T ,Credit Card, Western Union |
| Download | |
| Update Time | 2026-01-31 01:20:49 |
Shipping
Free Shipping
Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.
ESA TEXT HMI VT130W VT130W00000 Membrane Keyboard Replacement
HMI with 3” graphic LCD display, STN 4tones of blue, 160×80, 512 KB project,clock, 128 KB recipes, 25 operative keys(5 function keys, 20 customizable).Available also with Profibus-DPnetwork
ESA VIDEO TERMINAL (VT) is a device that allows the user to control orsimply monitor a productive process. It can send commands using configuredby the user; it can send data determining the process on hand andcan display information deriving from the productive process. The informationcan be in the form of an Alarm, an Information (Info-) Message or inbinary data format.
Kernfix supply ESA TEXT HMI VT130W membrane switch with 6 months warranty and support Urgent Worldwide Shipping.
Specifications:
| Brand: | ESA |
| Display Type: | TEXT LCD |
| Resolution: | 160 x 80 (3”) |
| Warranty: | 6-Months Warranty |
| Product Line: | VT TEXT |
| Columns by rows: | 20 * 4 |
| Display area size: | 67 x 37 |
| Input voltage: | 18 - 32 V DC |
| Part Number: | VT130W00000 |
Related BB Teach Pendant Part No. :
| VT130W00000 | Description | Inventory status |
| VT130W000DP | ESA Text HMI VT130W VT130W000DP Membrane Keypad Replacement | In Stock |
| VT130W00000 | ESA Text HMI VT130W VT130W00000 Membrane Keyboard Replacement | In Stock |
ESA Text HMI VT130W VT130W00000 Membrane Keyboard Replacement PDF Download:
FAQ:
Question: How to adjust the contrast on the ESA VT130W Display?
Answer: To improve the quality of the representation on the display it may be necessaryto adjust its contrast. This can be done by rotating the trimmer (C) atthe back of the VT ; turn it (using a small screwdriveror a trimmer tool) in one direction and, if the display quality worsens,turn it the other way.
Question: What is the VT130W Termination of CAN line?
Answer: The VT in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:• Make sure the device is not connected to the power supply.• Remove the cover.• Identify the jumper unit J2.• Position the jumper between pins 2 and 3 (line terminated).• Replace the back cover.• Reconnect the power supply.
Question: What is ESA VT130W mebrane keyboard HMI parts price?
Answer: Submit a fast quote, send Kernfix an email for best price.
