Koyo C-more Micro Panels EA1-S3ML-N HMI Switch Membrane

Koyo EA1-S3ML-N Keyboard Membrane Terminal Features
• 128 x 64 Dot display with up to 10 lines by 32 characters of text and graphics
• Up to 10 lines by 21 characters of dynamic text with embedded variables and phrases mixed with graphics
• 5 programmable function keys can change with every screen. Can increment/ decre- ment values, trigger recipes, view index of screens.
• 5-Color LED backlight for a longer lifetime; Green, Red, Amber, Yellow and Lime
• 2 optionalsnap-on keypad bezels
• 768 KB memory
• Panel is powered from PLC comm port when using select AutomationDirect PLCs. Use optional DC power adapter and serial port modules if needed for other controllers(RS-232/422/485)
• Built-in Alarm Controlsetup that activates beep, backlight flash, customized alarm banner, and LED blinking
• 0 to 50 °C (32 to 122 °F) operating temperature range (IEC 60068-2-14)
• NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only
• UL, cUL & CE agency approvals

C-more 3" Micro-Graphic EA1-S3ML-N STN Non-Touch
The EA1-S3ML-N Keypad Membrane C-more 3" Micro-Graphic non-touch panel has a 3.1-inch STN LCD monochrome display and five selectable LED-driven backlight colors: Green, Red, Amber, Yellow and Lime. It features a 128 x 64 dot display, and five user-defined function keys each with a user-defined red LED indicator. The panel can display up to 10 lines by 32 characters of static text and up to 10 lines by 21 characters of dynamic text with embedded variables and phrases mixed with graphics. It is rated UL for use on a flat surface of Type 1, 4X enclosure (for indoor use only). The EA1-S3ML-N Membrane Keypad Switch Micro-Graphic panel can receive power from the serial communications port of most AutomationDirect PLCs. An EA-MG-SP1 Serial Port with DC Power Adapter option module (RS-232/422/485) is required when using other controllers.
