M2I H TOP Series HTOP05TQ-SD2 Overlay Touch Screen

Order each part separately is available

Main Menu

It displays M2I H TOP Series HTOP05TQ-SD2 Touch Screen Monitor Protective Film TOP type and communication level, version, language, time and you can set it up. If you want to change time or language, you have to touch the value. It can set the HTOP05TQ-SD2 Front Overlay Touch Membrane parameters of Communication of COM1/COM2 Port, 2 Port(2Way)Communication.
N:1 Communication, Ethernet Communication. They should be same value with the parameter of Target PLC.
In case of communication of HTOP05TQ-SD2 Front Overlay Touch Digitizer Glass by CPU Module, another word target PLC be set as Loader Protocol in the Target PLC List of Project Information in XDesigner Plus, their value of communication setting are constant by each makers, so It is impossible to change the value of above COM1/COM2 In this Comm.

Setup Menu

For setting the Product configuration of M2I HTOP05TQ-SD2 Touch Screen Glass Protective Film, product have to be changed to the Main Menu Mode, in this Main Menu user can set the value of Communication Setup/Diagnosis/System Information and Set up.
In Setup Menu Screen of HTOP05TQ-SD2 Front Overlay Touch Panel, it can set the value of Power on Mode/Initial Screen Number/Screen Save/Buzzer/Latch Address/Printer/Password/Touch Sensitivity/LCD Brightness and Contrast/Initialize all setting.

Dignosis

It can test various items of H TOP Series HTOP05TQ-SD2 Touch Screen Film Protective Film like Test Page Print/Memory Diag./Touch key Diag./Display Diag./Comm. Diag./COM Port Diag./CF Card Diag.
