M2I XTOP Products Normal/EX TOPRX1200SD-Ex Glass Overlay

Order each part separately is available

Installation Requirements

1. For the performance, ventilation and safe use of the TOPRX1200SD-Ex Touch Screen Film Front Overlay equipment, keep the distance between the back of the main unit and each wall of the container at least 100mm and install the cooling fan when installed in an enclosed space.
2. It should be installed within -10~50C and 10~80%relative-humidity, otherwise the screen may be changed or cause malfunction and damage.
3. Be sure that heat from surrounding M2I XTOP Products Normal/EX Model TOPRX1200SD-Ex Protective Film Touch Membrane equipment does not cause product to exceed its standard operating temperature.
4. When you don't see within 30, you may not see clearly. When installing the product in a slanted position, the product screen should not incline more than 30.
5. In order to minimize external mechanical hazards of TOPRX1200SD-Ex Front Overlay HMI Panel Glass, please control the mechanical hazards of the surrounding environment.

Installation Procedure Warning

In order to install TOPRX1200SD-Ex Touch Screen Glass Protective Film product, please follow the following procedure.
1. Panel Cut-out: Make a panel cut which product is mounted and insert the product to the panel from the front side.
2. The Size of Panel Cut of TOPRX1200SD-Ex Touchscreen Front Overlay: Making the Panel Cut (Mounting Size) per each TOPRW Series as below Table, before Installation.
3. Fixing: Install clamps with this product should be installed as follows to maintain the IP performance of the device.
a.Insert the clamp into the slot of the product.
b.Screw the unit into the TOPRX1200SD-Ex Protective Film Touch Digitizer panel cut with a screwdriver.
