IDEC HG2G-5ST22VF-W Touch Display Front Overlay Repair
| Brand | IDEC |
|---|---|
| Model | HG2G-5ST22VF-W |
| Warranty | 365 Days |
| Supply parts | Touch Screen Tablet Protective Film |
| Shipping | 2-4 workdays |
| FOB port | Guangzhou, Shenzhen, Hongkong |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, T/T ,Credit Card, Western Union |
| Download | |
| Update Time | 2026-01-31 02:02:06 |
Shipping
Free Shipping
Those shipping costs are only estimates, the actual shipping cost will be shown on the order page.
IDEC HG2G 5.7in Enhanced HG2G-5ST22VF-W HMI Panel Screen Overlay Film Replacement
Order each part separately is available
Instruction for protective sheet
The Protective Sheet of HG2G-5ST22VF-W Touch Screen Glass Front Overlay is replaceable, transparent sheet to protect a display of IDEC HG series. With the protective sheet covered on the display, you can operate touch switches.
Adjusting the HG2G-5ST22VF-W Protective Film Touch Panel
A gap may be caused in the operation accuracy of the touch panel by the secular distortion, etc. Readjust the touch panel when there is a gap in the operation of the touch panel.
1. Wipe any dirt off the display using a soft cloth slightly dampened with neutral detergent or alcoholic solvent.
2. Remove the back sheet of the protective sheet.
3. The tab of the protective sheet should be positioned at lower left. Align the right side of the protective sheet with that of the HG2G-5ST22VF-W Touch Digitizer Glass Overlay Film, then apply the protective sheet onto the display. Care should be taken to avoid ingress of air.
4. On the top of protective sheet, a thin cover sheet is applied to prevent the protective sheet from being damaged during transportation. Remove it before using IDEC HG2G-5ST22VF-W Protective Film HMI Touch Glass.
When a protective sheet gets dirty or damaged, replace the protective sheet with a new one. When replacing the sheet, remove the used adhesives completely. The Protective Sheet has no protection effect against chemicals. HG2G-5ST22VF-W Touch Membrane Front Overlay has used a special material to filter out UV rays, however no warranty is given as to be installed in direct sunlight of outside.
Specifications:
| Storage Temperature: | -20 ~ 70°C |
| Model Number: | HG2G-5FT22TF-S |
| Product Line: | HG2G 5.7in Enhanced |
| Screen Type: | Analog Resistive Film |
| Operating Temperature: | -20 ~ 60°C |
| Display Size: | 5.7" |
| Operating Humidity: | 10 to 90% RH |
| Warranty: | 1-Year Warranty |
| Display Type: | 256 Color LCD |
| Brand: | IDEC |
Related BB Teach Pendant Part No. :
| HG2G-5ST22VF-W | Description | Inventory status |
| HG2G-5TN22TF-W | IDEC HG2G 5.7in Enhanced Touch Screen Glass Front Overlay Replacement | In Stock |
| HG2G-5TN22TF-W | IDEC HG2G 5.7in Enhanced HMI Panel Screen Protective Film Repair | Available Now |
| HG2G-5TT22TF-B | IDEC HG2G 5.7in Enhanced Touch Digitizer Overlay Film Replacement | In Stock |
| HG2G-5TT22TF-S | IDEC HG2G 5.7in Enhanced Touch Screen Glass Protective Film Repair | Available Now |
| HG2G-5TT22TF-W | IDEC HG2G 5.7in Enhanced Touch Screen Display Front Overlay Replacement | In Stock |
| HG2G-SB21TF-B | IDEC HG2G 5.7in Enhanced Protective Film HMI Panel Screen Repair | Available Now |
| HG2G-SB21TF-S | IDEC HG2G 5.7in Enhanced Touchscreen Monitor Front Overlay Replacement | In Stock |
| HG2G-SB21TF-W | IDEC HG2G 5.7in Enhanced Touch Screen Film Protective Film Repair | Available Now |
| HG2G-SB21VF-B | IDEC HG2G 5.7in Enhanced Front Overlay Touch Monitor Replacement | In Stock |
| HG2G-SB21VF-S | IDEC HG2G 5.7in Enhanced Protective Film Touch Membrane Repair | Available Now |
| HG2G-SB21VF-W | IDEC HG2G 5.7in Enhanced Touch Screen Tablet Front Overlay Replacement | In Stock |
| HG2G-SB22TF-B | IDEC HG2G 5.7in Enhanced Front Overlay Touch Screen Panel Repair | Available Now |
| HG2G-SB22TF-S | IDEC HG2G 5.7in Enhanced Touch Screen Tablet Protective Film Replacement | In Stock |
IDEC HG2G-5ST22VF-W Touch Display Front Overlay Repair PDF Download:
FAQ:
Question: How do I calibrate the touch screen on the HG2G-5ST22VF-W HMI?
Answer: To calibrate the touch panel of HG2G-5ST22VF-W, go to the calibration settings in the HMI menu. Follow the on-screen instructions to touch specific calibration points accurately. This process ensures accurate touch input across the screen.
Question: What are the screen types of HG2G-5ST22VF-W Terminal?
Answer: The screen types of HG2G-5ST22VF-W Machine are base screen, popup screen and system screen.
Question: How can I create and modify screens on the HG2G-5ST22VF-W HMI?
Answer: HG2G-5ST22VF-W HMI usually comes with dedicated software for screen development. Install the software on your computer, and then use it to design and customize screens with elements like buttons, images, text, and data display. The software often offers intuitive drag-and-drop interfaces for easy screen creation and modification.
