M2I Premium/Standard/ATEX TOPRD1020X Touchglass Overlay

Order each part separately is available

Screen calibration steps of Premium/Standard/ATEX Model TOPRD1020X Front Overlay Touch Panel

1. Turn the power of XTOP Module off.
2. When the power of TOP Module is on, keep the lower part of the screen is touched.
3. When the TOPRD1020X Protective Film HMI Panel screen is turned white color, remove your hand from the screen.
4. Then the screen display "Touch any point for Calibration" and the number is counted down.
5. Touch anywhere on the TOPRD1020X HMI Touch Glass screen Front Overlay before changing this number to "0".
6. Along with the message of Calibration Mode, touch the black square is indicated in the middle of the screen.
Continuously touch the TOPRD1020X Protective Film Touch Membrane upper left, upper right, lower left and lower right part's black square. When completed, the calibration is completed together with the message of Data Saving.

Specification and exchanging on battery

Turn off the TOPRD1020X Touch Digitizer Glass Protective Film product by using a screwdriver, open the battery case of product and exchange the battery. After exchange of battery, please do assemble the M2I TOPRD1020X Front Overlay Touch Screen Glass case again. Because rechargeable battery is built in, the internal memory is backed up when the battery is exchanged.
